Product Details:
|
| Touch Screen: | None | Car Entertainment System: | Yes |
|---|---|---|---|
| Air Conditioner: | Automatic | Headlight: | LED |
| Daytime Light: | LED | Front Window: | Electric |
| Rear Window: | Electric | Tyre: | 195 R14C |
| NEDC Max. Range: | 220km | Battery Charging Time(h): | Fast 2-2.5h,slow 14-16h |
| Battery Capacity(Kwh): | 41.86 | Body Structure: | Frameless Body |
| Maximum Gradeability (%): | ≥20 | Highest Speed(km/h): | 90 |
| Charging Mode: | EU Standard Charging Interface | Trunk/cargo Box Capacity (m³): | 6.01 |
| Rated Current (A): | 140 | ||
| Highlight: | 195 R14C New Energy Electric Truck,DONGFENG New Energy Electric Truck,RWD Dongfeng Electric Truck |
||
China New Car DONGFENG Electric Truck Small Cargo Truck Goods Train Lorry Electric
| Condition | New | Steering | Left |
| Emission Standard | Euro V | Made In | China |
| Type | Van | Fuel | Electric |
| Maximum Power(Ps) | 150-200Ps | Maximum Torque(Nm) | 200-300Nm |
| Wheelbase | 3000-3500mm | Number Of Seats | 2 |
| Curb Weight | 1000kg-2000kg | Cabin Structure | Integral Body |
| Drive | RWD | Front Suspension | Macpherson |
| Rear Suspension | Leaf Spring Non-independent Suspension | Steering System | Electric |
| Parking Brake | Manual | Brake System | Front Disc+Rear Drum |
| ABS(Antilock Braking System) | Yes | ESC(Electronic Stability Control System) | None |
| Radar | None | Rear Camera | Camera |
| Sunroof | None | Steering Wheel | Multi-function |
| Seats Material | Fabric | Driver's Seat Adjustment | Manual |
| Copilot Seat Adjustment | Manual | Touch Screen | None |
| Car Entertainment System | Yes | Air Conditioner | Automatic |
| Headlight | LED | Daytime Light | LED |
| Front Window | Electric | Rear Window | Electric |
| Tyre | 195 R14C | NEDC Max. Range | 220km |
| Battery Charging Time(h) | Fast 2-2.5h,slow 14-16h | Battery Capacity(Kwh) | 41.86 |
| Body Structure | Frameless Body | Maximum Gradeability (%) | ≥20 |
| Highest Speed(km/h) | 90 | Charging Mode | EU Standard Charging Interface |
| Trunk/cargo Box Capacity (m³) | 6.01 | Rated Current (A) | 140 |
|
Dimensions (mm) Length Width Height
|
4865*1715*2060
|
4865*1715*2060
|
|
Body structure
|
frameless body
|
frameless body
|
|
Wheelbase mm
|
3050
|
3050
|
|
Front/rear wheel track (mm)
|
1470/1450
|
1470/1450
|
|
Maximum design total GVW (kg)
|
3000
|
3000
|
|
Curb weight (kg)
|
1640
|
1640
|
|
Rated carrying passengers (persons)
|
2
|
2
|
|
Rated load weight (kg)
|
1230
|
1230
|
|
Maximum speed (km/h)
|
90
|
80
|
|
Maximum gradeability (%)
|
≥20
|
≥25
|
|
Range (km) operating method
|
220
|
170
|
|
Inside dimension of cargo box (length × width × height) (mm)
|
2670*1550*1350
|
2670*1550*1350
|
|
Trunk/cargo box Capacity (m³)
|
5.59
|
5.59
|
|
Electric motor type
|
permanent magnet synchronous motor
TZ180XS105 |
permanent magnet synchronous motor
TZ180XS105 |
|
Electric motor manufacturer
|
INOVANCE SUZHOU
|
INOVANCE SUZHOU
|
|
Motor rating/peak power (kW)
|
30/70
|
30/70
|
|
Motor rating/maximum torque (NM)
|
90/230
|
90/230
|
|
Motor rating/maximum speed (RPM)
|
3183/9000
|
3183/9000
|
|
Cooling mode
|
hydraulic
|
hydraulic
|
|
Protection grade
|
IP67
|
IP67
|
|
model
|
KTZ33X28S001
|
KTZ33X28S001
|
|
Controller Manufacturer
|
INOVANCE SUZHOU
|
INOVANCE SUZHOU
|
|
Rated current (A)
|
140
|
140
|
|
Cooling method (air-cooled/liquid-cooled)
|
hydraulic
|
hydraulic
|
|
Protection grade
|
IP67
|
IP67
|
|
Type of energy storage device (lithium iron phosphate/ternary)
|
LFP
|
LFP
|
|
Energy storage device assembly model
|
L125V01
|
L125V01
|
|
Energy storage device assembly production enterprises
|
CATL
|
CATL
|
|
Single model of energy storage device
|
CB220
|
CB220
|
|
Energy storage unit production enterprises
|
CATL
|
CATL
|
|
Total storage capacity of energy storage device (kWh)
|
41.86
|
41.86
|
|
Energy Storage Device Assembly Nominal Voltage (V)
|
334.88
|
334.88
|
|
Energy Storage Plant Assembly Nominal Capacity (AH)
|
125
|
125
|
|
Battery Charging Time Fast/Slow Charging (h)
|
fast 2-2.5h,slow 14-16h
|
fast 2-2.5h,slow 14-16h
|
|
Battery heating system
|
●
|
●
|
|
Rated power (3.3/6.6kW)
|
EU charging Port
|
EU charging Port
|
|
Cooling method (air-cooled/liquid-cooled)
|
hydraulic
|
hydraulic
|
|
Qty of speeds
|
3
|
3
|
|
Shifting device
|
Handle type electronic shift gear
|
Handle type electronic shift gear
|
|
Rear axle ratio
|
10.5
|
10.5
|
|
Drive mode (front/middle/rear, front/middle/rear drive)
|
RR
|
RR
|
|
Front suspension type
|
McPherson type independent suspension
|
McPherson type independent suspension
|
|
Rear suspension type
|
Sheet spring non-independent suspension
|
Sheet spring non-independent suspension
|
|
Steering assistance (hydraulic/electric)
|
electric
|
electric
|
|
Front and rear brake type (disc/drum)
|
Front disc/Rear drum
|
Front disc/Rear drum
|
|
Parking Brake (Electronic/Handbrake)
|
Hand brake
|
Hand brake
|
|
Tire size
|
195 R14C
|
195 R14C
|
|
Rim material (steel/aluminum alloy)
|
Iron
|
Iron
|
|
The spare tire
|
●
|
●
|
|
Near and far light lamp source (halogen/xenon /LED)
|
LED
|
LED
|
|
LED daytime running lights
|
●
|
●
|
|
front fog lamp
|
●
|
●
|
|
rear fog lamps
|
●
|
●
|
|
Reverse lamp
|
●
|
●
|
|
High brake lamp
|
●
|
●
|
|
Cargo box dome lamp
|
●
|
●
|
|
Headlight height adjustable (manual/electric)
|
electric
|
electric
|
|
Reading lamp
|
●
|
●
|
|
Window lifting (electric/manual)
|
electric
|
electric
|
|
External rearview mirror adjustment (manual/electric)
|
manual
|
manual
|
|
Interior cosmetic mirror
|
passenger
|
passenger
|
|
Inside rearview mirror - manual mode
|
●
|
●
|
|
Seat belts
|
●
|
●
|
|
Safe shake handshandle
|
1
|
1
|
|
Electric central control door lock
|
●
|
●
|
|
ABS antilock
|
●
|
●
|
|
Alarm when the vehicle is under high pressure
|
●
|
●
|
|
Low speed signal
|
●
|
●
|
|
Door door open reminder
|
●
|
●
|
|
No seatbelt alert
|
DRIVER● PASSENGER●
|
DRIVER● PASSENGER●
|
|
Remote terminal monitoring system
|
●
|
●
|
|
Reversing radar
|
—
|
—
|
|
Reversing camera
|
—
|
—
|
|
Mechanical keys
|
1
|
1
|
|
Remote control key
|
1
|
1
|
|
Steering wheel position adjustment (manual/electric, 2-way / 4-way)
|
—
|
—
|
|
Electric horn (horn for driving whistle)
|
●
|
●
|
|
Combination instrument
|
●
|
●
|
|
Air conditioning refrigeration (manual/automatic)
|
manual
|
manual
|
|
PTC heating
|
●
|
●
|
|
Visor
|
DRIVER● PASSENGER●
|
DRIVER● PASSENGER●
|
|
Cigarette lighter
|
●
|
,●
|
|
Cab carpet (fabric/nylon /PVC etc.)
|
PVC●
|
PVC●
|
|
Trunk/Carpet (fabric/nylon /PVC/ aluminum alloy, etc.)
|
aluminium alloy●
|
aluminium alloy●
|
|
Inside container skin
|
●
|
●
|
|
Car roof outside the antenna
|
●
|
●
|
|
Inside the door to protect the plate storage space
|
●
|
●
|
|
Dashboard storage box/cup holder
|
●
|
●
|
|
Dashboard storage box/cup holder
|
●
|
●
|
|
Ceiling
|
●
|
●
|
|
Trunk lid open (manual/electric)
|
manual
|
manual
|
|
Seat material (fabric/leather)
|
fabric
|
fabric
|
|
Main drive seat adjustment mode (manual/electric, 4/6/8 direction)
|
manual 4 direction●
|
manual 4 direction●
|
|
First seat adjustment mode (manual/electric, 4/6/8 direction)
|
manual 4 direction●
|
manual 4 direction●
|
|
Master/first officer seat headrest height adjustment
|
●
|
●
|
|
Radio
|
●
|
●
|
|
External antenna
|
●
|
●
|
|
USB/AUX interface
|
●
|
●
|
|
Interior color
|
Dark gray
|
Dark gray
|
|
Outside rearview mirror housing color
|
black
|
black
|
|
Front and rear bumper colors
|
same as body
|
same as body
|
|
High level brake light
|
●
|
●
|
|
Automatic headlights on
|
●
|
●
|
|
Seat belt not fastened (driver/passenger)
|
●
|
●
|
|
Daytime running light
|
●
|
●
|
|
Trolley low speed warning system
|
●
|
●
|
