Product Details:
|
| Seats: | 48 | Emission Standard: | Electric |
|---|---|---|---|
| Transmission Type: | Automatic | Max Speed: | 100 Km/h |
| Steering Position: | LHD | Fuel Type: | Electric |
| Dimensions (L X W X H) (mm): | 10900*2540*3470,3340 | Tyre: | 11R22.5 |
| GVW: | 18000kg | Rated Passenger/Seats: | 24-48 |
| Highest Speed: | 100km/h | Wheelbase: | 5400mm |
| Motor Power (KW): | 165/240 | Color: | Customer's Request |
| NEDC Max. Range: | 456KM | Battery Energy(kWh): | 229.05 |
| Port: | Any Port In China | ||
| Highlight: | NVH Electric City Buses,48 Seats Electric City Buses,NVH City Tourist Bus |
||
|
Confirguration
|
Item
|
T11
|
|
|
Configuration Parameter
|
Dimension (mm)
|
10900×2540×3470,3340
|
|
|
Steering
|
Left
|
||
|
Tire
|
11R22.5
|
||
|
Wheelbase (mm)
|
5400
|
||
|
Rated passenger/Seats
|
24-48
|
||
|
Mileage
|
456km
|
||
|
GVW
|
18000kg
|
||
|
Curb Weight(KG)
|
11800,11500
|
||
|
Power Battery
|
Type
|
Lithium Iron Phosphate
|
|
|
Battery Capacity
|
229.05kwh
|
||
High strength steel closed ring structure, better anti-roll rolling deformation effect, front suspension overhanging air bag, rear suspension C-type suspension, increase roll stiffness, better anti-roll stability, effectively ensure the safety of passengers;
Air suspension, good comfort; ride more comfortable, travel more comfortable; Optimized control strategy, using NVH mute technology, effectively reduce vehicle noise up to 10 decibels, more comfortable ride
