Product Details:
|
| Seats: | 21 - 40 | Emission Standard: | Electric |
|---|---|---|---|
| Transmission Type: | Automatic | Max Speed: | 51 - 70 Km/h |
| Steering Position: | LHD | Fuel Type: | Electric |
| Dimensions (L X W X H) (mm): | 10500*2500*3380 | Tyre: | 275/70R22.5 |
| GVW: | 18000kg | Rated Passenger/Seats: | 88/20-31,79/20-39 |
| Highest Speed: | 69km/h | Wheelbase: | 5800mm |
| Motor Power (KW): | 100/200 | Color: | Customer's Request |
| NEDC Max. Range(KM): | 475 | Maximum Gradeability(%): | 20 |
| Battery Energy(kWh): | 255.48 | Port: | Any Port In China |
| Highlight: | 10M Electric City Buses,88 People Electric City Buses,Wheelbase 5800mm Electric Vehicle Bus |
||
|
Confirguration
|
Item
|
C10
|
||
|
Configuration Parameter
|
Dimension (mm)
|
10500*2500*3380
|
||
|
|
Steering
|
Left
|
||
|
|
Tire
|
275/70R22.5
|
||
|
|
Wheelbase (mm)
|
5800
|
||
|
|
Rated passenger/Seats
|
88/20-31,79/20-39
|
||
|
|
Mileage(KM)
|
475
|
||
|
|
GVW
|
18000kg
|
||
|
|
Curb Weight(KG)
|
11000
|
||
|
Power Battery
|
Type
|
Lithium Iron Phosphate
|
||
|
|
Battery Capacity
|
255.48kwh
|
||
Equipped with T6 pure electric drive system, the highest efficiency point is more than 96%; Large torque permanent magnet synchronous motor, climbing slope > 20°; It has a lithium iron phosphate battery with a maximum range of 520km.
Lightweight design, body weight reduced 200Kg; The application of high strength steel QStE700TM, the structural strength of the vehicle is doubled; Equipped with driving achievement system, driving behavior factors that affect energy consumption can be quantified to enhance drivers' sense of participation and awareness of energy saving, and promote energy saving and consumption reduction; The driving and auxiliary "power consumption" efficiency was comprehensively improved, and the energy consumption was reduced by 10%. Automatic optimization torque control algorithm, braking recovery energy ≥40%
